100V series

SRT Microcéramique Low Voltage High Capacitance X7R Capacitors

High capacitance SMD capacitors
Capacitance from 1.0µF to 47µF
TCR of ±15% with 0Vdc applied
Voltages from 4V to 100V
IR 25°C/Un 10⁴MΩ / 500Ω-Farad whichever is less *
Dielectric X7R
Operating temperatures of -55°C to +125°C **

Coto 9011 Series

Miniature moulded reed relays
High insulation resistance of 10¹²Ω minimum
Switching current 0.25A
Optional coil suppression diode
External magnetic shielding reduces interaction
Temperature range −20°C to +85°C

Exxelia Ohmcraft HC 0403

Bondable SMD Resistors
Resistance range from 10kΩ to 10GΩ
Tolerances from ±1% to ±20%
TCR from ±50 ppm/°C to >200 ppm/°C
Power rating of 0.055W
Voltage rating of 100V
Temperature range from -55°C to +150°C

Exxelia Ohmcraft HC 0404

Bondable SMD Resistors
Resistance range from 10kΩ to 10GΩ
Tolerances from ±1% to ±20%
TCR from ±50 ppm/°C to >±200 ppm/°C
Power rating of 0.06W
Voltage rating of 100V
Temperature range from -55°C to +150°C

Exxelia Ohmcraft HC 0502

Bondable SMD Resistors
Resistance range from 10kΩ to 10GΩ
Tolerances from ±1% to ±20%
TCR from ±50 ppm/°C to >±200 ppm/°C
Power rating of 0.05W
Voltage rating of 100V
Temperature range from -55°C to +150°C

Exxelia Ohmcraft HC 0505

Bondable SMD Resistors
Resistance range from 10kΩ to 10GΩ
Tolerances from ±1% to ±20%
TCR from ±50 ppm/°C to >±200 ppm/°C
Power rating of 0.1W
Voltage rating of 100V
Temperature range from -55°C to +150°C

Exxelia Ohmcraft SM 0603

High Ohmic SMD Resistors
Resistance range from 10kΩ to 50GΩ
Tolerances from ±0.5% to ±20%
TCR of ±50 ppm/°C, ±100 ppm/°C or ±200 ppm/°C
Power rating of 0.06W
Voltage rating of 100V
Temperature range from -55°C to +150°C

SRT Microcéramique Chip Capacitors with Negative TC

NP0 (C0G) Chip ceramic capacitor with negative TC
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor under 10.10^-4 at 1V_rms and 1kH (or 1MHz)
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique High Frequency Capacitor Series

MLCC Capacitor for RF and Microwave communication
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor under 5.10^-4 at 1V_rms and 1MHz for values ≤ 1000pF and under 5.10^-4 at 1V_rms and 1KHz for values > 1000pF
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique High Temperature NP0 Capacitor Series

High Temperature, ultra stable MLCC Capacitor
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor under 10.10^-4 at 1V_rms and 1kHz (or 1MHz)
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique High Temperature X7R Capacitor Series

High Temperature MLCC Capacitor
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor up to 0.025
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique Low Voltage BX Capacitor Series (50-100V)

Stable ceramic capacitor
Better voltage behaviour compared to X7R dielectric
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor up to 0.025 at 1kHz for C over 1nF, and up to 0.025 at 1MHz for C up to 1nF
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique Low Voltage NP0 Capacitor Series (16-100V)

Ultra stable ceramic capacitor
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor under 10.10^-4 at 1V_rms and 1kHz (or 1MHz)
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique Low Voltage X7R Capacitor Series (16-100V)

Stable ceramic capacitor
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor up to 0.025 at 1kHz for C over 1nF, and up to 0.025 at 1MHz for C up to 1nF
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique Non Magnetic NP0 Capacitor Series

Non magnetic NP0 (Type 1) MLCC Capacitors
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor under 10.10^-4 at 1V_rms and 1kHz (or 1MHz)
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique Non Magnetic X7R Capacitor Series

Non magnetic X7R (Type 2) MLCC Capacitors
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor maximum of 2.5% at 1V_rms and 1kHz for Un between 16V and 25V and maximum 1% at 1V_rms and 1kHz for Un between 25V and 50V
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
