Miniature-Satellite Series Pressure Transmitter

Emerson’s Paine™ 212-35-070-05K0 miniature satellite and space pressure transmitter series is designed with Class ‘S’, QML-V / ELDRS free electronics to meet EEE INST-002/ MSFCSTD- 3012 Level 1 standards. This transmitter series from Emerson offers a pressure range of 0 – 5,000 PSIA and provides reliable measurement in mission critical applications. This high-performance transmitter features low mass of 75 grams, radiation hardening to 100KRad (Si) total dose and accuracy of ±1.5% full scale. Applications include fuel tank pressure and thrust-er propellant pressure.

• Miniature satellite and space pressure transmitter
• Pressure range of 0 – 5,000 PSIA
• All welded stainless steel construction
• Input voltage of ±12 – 15VDC
• Temperature range of −40°C to +60°C
• Designed with Class ‘S’, QML-V / ELDRS free electronics to meet EEE INST-002/ MSFCSTD- 3012 Level 1 standards
• Performs in orbital environments with radiation hardening/rating to 100KRad (Si) total dose
• Output voltage of 0.1 to 5.1VDC
• Accuracy of ±1.5% of the full scale over the calibrated temperature range
• Features immunity to Single Event Latch up (SEL)
• Customisation transmitter options available for fit-for-use designs
• Process media any compatible with 15-5 PH CRES & 321 CRES

The 212-35-070-05K0 series offers an all welded stainless steel construction that provides high measurement performance, accuracy and reliability in mission critical applications.

Potential applications for the Paine™ 212-35-070-05K0 series include:

• Fuel tank pressure monitoring
• Thrust pressure monitoring
• Pressure regulator systems
• Oxygen pressure monitoring
• Space probe servo valve controls
• ROV maneuvering controls

Please see the pressure table below for the Paine™ 212-35-070-05K0, which includes details on standard products available as well as proof and burst pressure ratings:
