The SV 7.62HP/180G high power, male header PCB plug in connector series from Weidmüller’s Omnimate power range, has been designed with a conductor outlet direction of 180°. They have a 7.62mm pitch and a choice from 2 up to 12 poles. The SV 7.62HP/1800G series from Weidmüller with a high power rating of 57A (IEC) and 40.5A (UL approved), closed housing and are suitable for wave (THT) soldering. These PCB plug-in connectors have an operating temperature range of −50°C up to +130°C .
The below table gives the specifications of the Weidmüller SV 7.62HP/180G PCB connector series:
Weight | 0.00000 kg |
---|---|
Dimensions | 0.00 x 0.00 x 0.00mm |
Colour | Black |
Conductor Outlet Direction | 180° |
Number of Poles | 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12 |
Package / Size | |
Series / Model | |
Termination / Connection | Male Header |
SKU | Number of Poles |
---|---|
Weidmüller SV 7.62HP/180G Series | 10 |
Weidmüller SV 7.62HP/180G Series | 11 |
Weidmüller SV 7.62HP/180G Series | 12 |
Weidmüller SV 7.62HP/180G Series | 2 |
Weidmüller SV 7.62HP/180G Series | 3 |
Weidmüller SV 7.62HP/180G Series | 4 |
Weidmüller SV 7.62HP/180G Series | 5 |
Weidmüller SV 7.62HP/180G Series | 6 |
Weidmüller SV 7.62HP/180G Series | 7 |
Weidmüller SV 7.62HP/180G Series | 8 |
Weidmüller SV 7.62HP/180G Series | 9 |
Product name | SKU | Datasheet | ||
---|---|---|---|---|
Weidmüller SV 7.62HP/180G Series | Weidmüller SV 7.62HP | View Product | ||
Weidmüller SV 7.62HP/90G Series | Weidmüller SV 7.62HP | View Product |
This product is available fully compliant to the RoHS EU directive 2011/65/EU.
