Ametherm SL32 5R020

The SL32 5R020 inrush current limiting thermistor from Ametherm offers a maximum steady state current of 20A (up to +25°C), resistance of 5Ω ±20% (at 20°C) and a maximum recommended energy rating of 200J. The Ametherm SL series suppresses surge currents that occur when electrical circuits are switched on, preventing serious damage to sensitive electronic components if their rated current values are exceeded. Connected in series with the load, at “switch-on” they limit the current due to its relatively high cold resistance. As a result of current flow, the thermistor self-heats and in turn reducing its resistance value so that once the initial surge current has been safely held off, the resistance in the thermistor is maintained at a low value to maximise efficiency

• Inrush current limiting thermistor
• Resistance of 5Ω (at 25°C)
• Maximum steady state current of 20A (up to +25°C)
• Maximum recommended energy of 200J
• Voltage ratings of 120VAC and 240VAC
• Actual energy failure at 300J
• 0.03Ω at 100% maximum current and 0.08Ω at 50% maximum current
• Body temperature of +206°C at maximum current
• Material type H (for beta and curve)
• Dissipation constant of 45.4mW/°C
• Tolerance ±20%
• Thermal time constant of 194mW/s
• Recognised by Underwriters Laboratories (UL) and Canadian Standards Association (CSA) for ensured safety

Typical applications for the SL series include:

• Limit current inrush to PSUs and battery chargers
• Lighting circuits and thermostat protection
• Electric motor soft start

The below table gives the full specifications of the Ametherm SL32 5R020 series:
