The 3541 surface-mount low thermal EMF reed relay series from Coto features available coil voltage options of 5V_DC and 12V_DC with a switching voltage of 500V and switching current of 0.5A. The 3541 series is designed to offer a low thermal EMF range of <3µV and <5µV. An epoxy coated steel shell provides magnetic shielding, with hermetically sealed contacts for long life and high reliability. The 3541 series is ideally suited to the needs of instrumentation, data acquisition and process control

• Surface-mount low thermal EMF reed relay
• Nominal coil voltage options of 5V_DC and 12V_DC
• Contact form of 2A
• Switching voltage of 500V
• Dielectric strength of 1500V_DC
• Thermal EMF options of <3µV and <5µV available
• Contact rating 10W
• Switching current 0.5A
• High insulation resistance of 10¹²Ω minimum
• Temperature range −20°C to +85°C
• Potted package size

Typical Applications include:

• High accuracy DVM’s
• Multiplexers
• Digital or analog multi-point recorders

For further information regarding coil specifications, contact ratings and relay specifications please see the datasheet on the Technical Library tab.
