Reed Relay

The 2911 series reed relay from Coto features available coil voltage options of 5V_DC and 12V_DC with a switching voltage of 150V and switching current of 0.25A with optional electrostatic shield for reducing capacitive coupling, coaxial shielding for 50Ω impedance. The 2911 series from Coto are considered ideal for high speed switching compared to electromechanical relays, very small footprint of 0.2in². They have hermetically sealed contacts for long life and their epoxy coated steel shell provides magnetic shielding. The 2911 series are ideally suited to the needs of automated test equipment and RF requirements, specifically engineered for OEM designs and maintenance of existing production fixtures.

• Reed relay
• Nominal coil voltage options of 5V_DC and 12V_DC
• Contact form of 1C
• Switching voltage of 200V
• Dielectric strength of 200V_DC
• Contact rating 3W
• Switching current 0.25A
• Shielding options available electrostatic, coaxial or no shielding
• Temperature range −20°C to +85°C
• Encapsulated PICO package

Typical Applications include:

• Automated test equipment
• RF requirements

Coto is a worldwide market leader of small signal-switching products sold into the Automatic Test Equipment, Data Acquisition, Instrumentation, Process Control, Telecommunications, Medical and Security markets. Coto specialises in the manufacture of relay, switch and sensor products. Coto are the pioneers of the RedRock® analog and digital TMR magnetic sensors, offering the lowest power consumption, highest sensitivity, ultra-miniature package size, short lead times and a highly-competitive price. Please visit https://cotorelay.com/ for more information.
