SRT Microcéramique High Power Low Frequency Capacitor Series

MLCC high power, low capacitance variation with voltage capacitors
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor under 10.10^-4 at 1V_rms and 1kHz (or 1MHz)
Insulation resistance under 20000 MOhm or 500 Ohm-Farad at 25°C under 500V
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique High Voltage X7R Capacitor Series (200V-1kV)

Stable ceramic capacitor
High quality and reliability, suitable for safety-critical industries
Dissipation factor up to 0.025 at 1kHz for C over 1nF, and up to 0.025 at 1MHz for C up to 1nF
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique High Voltage X7R Capacitor Series (2kV-10kV)

Stable ceramic capacitor
High quality and reliability, suitable for safety-critical industries
Dissipation factor up to 0.025 at 1kHz for C over 1nF, and up to 0.025 at 1MHz for C up to 1nF
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique RF Power High Frequency Capacitor Series

MLCC RF power, high frequency capacitors for RF instruments, lasers and similar applications
Highest quality and reliability, suitable for safety-critical industries
Dissipation factor under 5.10^-4 at 1V_rms and 1MHz for values ≤ 1000pF and under 5.10^-4 at 1V_rms and 1KHz for values > 1000pF
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less and 125°C/Un 10⁴ MΩ or 100 Ohm-Farad whichever is less
Dielectric strength test performed per method 103 of EIA 198-2-E

SRT Microcéramique X7R Capacitor Stack Series

X7R capacitor stacks, ideal for input/output filtering in SMPS applications
Highest quality and reliability, suitable for safety-critical industries
Maximum dissipation factor of 2.5% at 1V_rms, 1kHz, 25°C
Insulation resistance of 25°C/Un 10⁵ MΩ or 1000 Ohm-Farad whichever is less
Dielectric withstanding voltage of 2.5Un for 5s with 50mA maximum charging current
